| Available Materials | Galvalume (22, 24 gauge), Aluminum (.032, .040, .050), Copper (16 & 20 oz) |
| Substrate Requirements | Can be installed over Solid Substrate |
| Underlayment | Ice & Water Shield (Recommended) or Synthetic Underlayment. |
| Color Gallery | View |
| Testing - UL Listings | UL 580 Class 90 (Uplift), UL 790 (Class A Fire Rating), UL 2218 (Impact Resistant) |
| Testing -ASTM | ASTM 1592 (Uplift) Aluminum, Galvalume |
| Available Widths | 12” – 20” |
| Finish | Kynar 500 (Fluoropolymer PVDF Coating) |
| Testing - ASCE | Can be engineered to current ASCE 7 design standard |
| Panel Options | Striations (Recommended), Stress Ribs, Curved/Radius, Flat (Not Recommended) |
| Minimum Roof Pitch | 3:12 |
