| Available Materials | Galvalume (22, 24 gauge), Aluminum (.032, .040), Copper (16 oz) |
| Finish | Kynar 500 (Fluoropolymer PVDF Coating) |
| Substrate Requirements | Can be installed over Solid Substrate, Minimum Roof Pitch, 3:12 |
| Underlayment | Ice & Water Shield (Recommened) or Synthetic Underlayment. |
| Available Widths | 12” – 18” |
| Color Gallery | View |
| Testing - UL Listings | UL 580 Class 90 (Uplift), UL 790 (Class A Fire Rating), UL 2218 (Impact Resistant) |
| Testing -ASTM | ASTM 1592 (Uplift) Aluminum, Galvalume, ASTM 1646 (Water Penetration), ASTM 1680 (Air Infiltration), ASTM 2140 (Static Water Penetration) |
| Testing - ASCE | Can be engineered to current ASCE 7 design standard |
| Panel Options | Striations (Recommended), Flat, Stress Ribs, * Factory applied Seam Sealant |
